MENRED C2 Series Heating Manifold and SEH32 Thermal Actuator

Application

Huajian Jinyuan | Chengdu, Sichuan

Characteristics

1. Organized Heating Water Distribution

The MENRED C2 Series Manifold is designed to connect the heating water supply with multiple underfloor heating circuits. Its centralized configuration provides an organized arrangement for residential hydronic heating distribution.

2. Forged Brass Manifold Construction

The C2 Series features a high-density forged brass structure with an integrated main body. Combined with axial static sealing, the design helps minimize potential leakage points at the manifold.

3. Automatic Heating Valve Actuation

The SEH32 Thermal Actuator operates compatible heating circuit valves through an electrothermal drive mechanism. Its low-noise operation makes it suitable for valve control in residential heating applications.

More about the project

Huajian Jinyuan is a residential project in Chengdu, China, featuring MENRED C2 Series Heating Manifolds and SEH32 Thermal Actuators.

In hydronic underfloor heating systems, the manifold plays an essential role in organizing heating water distribution. Individual heating circuits are connected to the manifold, allowing the heating water supply to be distributed through separate floor heating loops.

For this application, the MENRED C2 Series provides the central distribution component. Its integrated brass structure and sealing design support dependable operation in residential heating installations.

The SEH32 Thermal Actuator complements the manifold by enabling electrically operated valve control. This allows compatible heating circuits to respond to control signals when incorporated into a properly designed heating control system.

The Huajian Jinyuan project demonstrates the application of MENRED manifold and actuator components in residential hydronic heating infrastructure.
